USCG Illustrations Workbooks for the USCG Marine Engineering License Exam

Alan Gillis

Mattapoisett MA 02739

info@uscgillustrationsworkbooks.com


USCG Illustrations Workbooks

2022 Illustrations Workbooks

The NEW 2022 Illustrations Workbooks are now available!  The FOUR volume set includes all of the new USCG Engineering Illustrations that have been released.

Volume 1:  Motor Plants includes discussion and solutions for all 195 Motor illustrations.

Volume 2:  General Subjects and Refrigeration includes discussion and solutions for 180 General illustrations and 69 Refrigeration illustrations.

Volume 3:  Gas Turbines, Safety, and Steam Plants includes discussion and solutions for 31 Gas Turbine, 48 Safety, and 49 Steam Plants illustrations.

Volume 4:  ELECTRICAL includes discussion and solutions for 261 Electrical Illustrations plus all math solutions and CFR references for the electrical questions.
